Features Advanced DDS technology, up to 5 MHz frequency output 125 MS/s sample rate and 1 μHz frequency resolution Vertical Resolution: 14 bits and 8K arb waveform length Comprehensive waveform output: 5 basic waveforms and 45 built-in arbitrary waveforms SCPI and LabVIEW supported 4'' high resolution (480 x 320 pixels) LCD Could work with OWON SDS Series DSO smoothly Please note: The photos show 3 additional buttons (Mod, Sweep, Burst) that are not available on the currently available version of the device Specifications Channel Single + Trigger Frequency Output 5 MHz Sample Rate 125 MS/s Vertical Resolution 14 bits Waveform Standard Waveform Sine, Square, Pulse, Ramp, and Noise Arbitrary Waveform Exponential Rise, Exponential Fall, Sin(x)/x, Step Wave, and others, total 45 built-in waveforms, and user-defined arbitrary waveform Frequency (resolution 1 μHz) Sine 1 μHz - 5 MHz Square 1 μHz - 5 MHz Pulse 1 μHz - 5 MHz Ramp 1 μHz - 1 MHz Noise 5 MHz (-3 dB) (typical) Arb 1 μHz - 5 MHz Amplitude Amplitude 1 m Vpp - 12.5 Vpp (50 Ω) 1 m Vpp - 25 Vpp (high impedance) Resolution 1 m Vpp, or 4 digits DC Offset Range (AD+DC) ±6.25 V (50 Ω), ±12.5 V (high impedance) DC Offset Range Resolution 1 mV, or 4 digits Load Impedance 50 Ω (typical) Arbitrary Waveform Wave Length 2 pts to 8K pts Sample Rate 125 MS/s Vertical Resolution 14 bits Non-volatile Memory 64 M bytes Input / Output Display 4' (480 x 320 pixels) LCD Type External reference clock input Communication Interface USB device Mechanical Dimension (W x H x D) 235 x 110 x 295 mm Device Weight 3 kg
Features 2-in-1 station: Oscilloscope + 3¾ digits multimeter + FFT spectrum analyzer Auto-scale Function: While in auto-scale status, the oscilloscope will switch to the specific trigger mode, vertical scale, and timebase scale according to the type, amplitude, and frequency of the input signal. Trigger Sensitivity Adjustable: While in auto-scale status, the oscilloscope will switch to the specific trigger mode, vertical scale, and timebase scale according to the type, amplitude, and frequency of the input signal. Alternative trigger function: OWON HDS digital oscilloscope alternative trigger function support two simultaneous signal test, improve working efficiency. Rechargeable Li-ion battery (6 hours' backup) Multimeter newly supported SCPI USB data transmission supported Bandwidth: 20 MHz – 200 MHz 20 group automatic measurement options Waveform record & restore
The OWON HDS2102s is a portable 3-in-1 multifunctional tester, which can be used as a 2-ch oscilloscope with a bandwidth of 100 MHz, multimeter and signal generator. It features a high-contrast 3.5-inch color display suitable for outdoor facility maintenance, rapid on-site measurement, automobile maintenance, power detection. etc.Features
Oscilloscope + multimeter + waveform generator, multifunction in one
3.5-inch high-resolution, high-contrast color LCD display, suitable for outdoor use
18650 lithium battery, can work continuously for 3-6 hours
USB Type-C interface, support power bank, support PC software connection
Self-calibration function
SCPI supported, facilitate secondary development
Specifications
Bandwidth
100 MHz
Channels
2-ch Oscilloscope + 1-ch Generator
Sample Rate
500 MSa/s
Acquisition Model
Normal, Peak detect
Record Length
8K
Display
3.5-inch LCD
Waveform Refresh Rate
10,000 wfrms/s
Input Coupling
DC, AC, and Ground
Input Impedance
1 MΩ ±2%, in parallel with 16pF ±10pF
Probe Attenuation Factors
1X,10X,100X,1000X,10000X
Max. input Voltage
400 V (DC+AC, PK-PK, 1MΩ input impedance) (10:1 probe attenuation)
Bandwidth Limit (typical)
20 MHz
Horizontal Scale
2ns/div - 1000s/div, step by 1 - 2 - 5
Vertical Sensitivity
10mV/div - 10V/div
Vertical Resolution
8 bits
Trigger Type
Edge
Trigger Modes
Auto, Normal, single
Automatic Measurement
Frequency, Period, Amplitude, Max, Min, Mean, PK-PK
Cursor Measurement
ΔV, ΔT, ΔT&ΔV between cursors
Communication Interface
USB Type-C
Multimeter Specifications
Max. Resolution
20,000 counts
Testing Mode
Voltage, Current, Resistance, Capacitance, Diode, and Continuity test
Input Impedance
10 MΩ
Max Input Voltage
AC 750 V, DC 1000 V
Max Input Current
DC: 10 A, AC: 10 A
Diode
0-2 V
Waveform Generator Specifications
Frequency Output
Sine
0.1 Hz - 25 MHz
Square
0.1 Hz - 5MHz
Ramp
0.1 Hz - 1 MHz
Pulse
0.1 Hz - 5 MHz
Arbitrary
0.1 Hz - 5 MHz
Sampling Rate
125 MSa/s
Channel
1-ch
Amplitude Range (high impedance)
20 mVpp - 5 Vpp
Waveform Length
8K
Vertical Resolution
14 bits
Output Impedance
50Ω
Included
1x OWON HDS2102s
1x Power adapter
1x USB cable
1x Passive probes
2x Crocodile clip cable
1x Set of multimeter probes (one red and one black)
1x User manual
1x Probe correction adjustment knife
Downloads
User Manual
Specifications
SCPI Protocol
Quick Guide
Software
The OWON HDS2202s is a portable 3-in-1 multifunctional tester, which can be used as a 2-ch oscilloscope with a bandwidth of 200 MHz, multimeter and signal generator. It features a high-contrast 3.5-inch color display suitable for outdoor facility maintenance, rapid on-site measurement, automobile maintenance, power detection. etc. Features Oscilloscope + multimeter + waveform generator, multifunction in one 3.5-inch high-resolution, high-contrast color LCD display, suitable for outdoor use 18650 lithium battery, can work continuously for 3-6 hours USB Type-C interface, support power bank, support PC software connection Self-calibration function SCPI supported, facilitate secondary development Specifications Bandwidth 200 MHz Channels 2-ch Oscilloscope + 1-ch Generator Sample Rate 1 GSa/s Acquisition Model Normal, Peak detect Record Length 8K Display 3.5-inch LCD Waveform Refresh Rate 10,000 wfrms/s Input Coupling DC, AC, and Ground Input Impedance 1 MΩ ±2%, in parallel with 16pF ±10pF Probe Attenuation Factors 1X,10X,100X,1000X,10000X Max. input Voltage 400 V (DC+AC, PK-PK, 1MΩ input impedance) (10:1 probe attenuation) Bandwidth Limit (typical) 20 MHz Horizontal Scale 2ns/div - 1000s/div, step by 1 - 2 - 5 Vertical Sensitivity 10mV/div - 10V/div Vertical Resolution 8 bits Trigger Type Edge Trigger Modes Auto, Normal, single Automatic Measurement Frequency, Period, Amplitude, Max, Min, Mean, PK-PK Cursor Measurement ΔV, ΔT, ΔT&ΔV between cursors Communication Interface USB Type-C Multimeter Specifications Max. Resolution 20,000 counts Testing Mode Voltage, Current, Resistance, Capacitance, Diode, and Continuity test Input Impedance 10 MΩ Max Input Voltage AC 750 V, DC 1000 V Max Input Current DC: 10 A, AC: 10 A Diode 0-2 V Waveform Generator Specifications Frequency Output Sine 0.1 Hz - 25 MHz Square 0.1 Hz - 5MHz Ramp 0.1 Hz - 1 MHz Pulse 0.1 Hz - 5 MHz Arbitrary 0.1 Hz - 5 MHz Sampling Rate 125 MSa/s Channel 1-ch Amplitude Range (high impedance) 20 mVpp - 5 Vpp Waveform Length 8K Vertical Resolution 14 bits Output Impedance 50Ω Included 1x OWON HDS2202s 1x Power adapter 1x USB cable 1x Passive probes 2x Crocodile clip cable 1x Set of multimeter probes (one red and one black) 1x User manual 1x Probe correction adjustment knife Downloads User Manual Specifications SCPI Protocol Quick Guide Software
The HDS242 is a portable 2-in-1 multifunctional tester, which can be used as a 2-ch oscilloscope and multimeter. It features a high-contrast 3.5-inch color display suitable for outdoor facility maintenance, rapid on-site measurement, automobile maintenance, power detection. etc. Features Oscilloscope + Multimeter 3.5-inch high-resolution, high-contrast color LCD display – suitable for outdoor use 18650 lithium battery – can work continuously for up to 6 hours USB Type-C interface – support power bank and PC connection Self-calibration function SCPI supported – facilitate secondary development Specifications Oscilloscope Bandwidth 40 MHz Channels 2-ch Oscilloscope Sample Rate 250 MSa/s Acquisition Model Normal, Peak detect Record Length 8K Display 3.5-inch LCD Waveform Refresh Rate 10,000 wfrms/s Input Coupling DC, AC, and Ground Input Impedance 1 MΩ ±2%, in parallel with 16pF ±10pF Probe Attenuation Factors 1X, 10X, 100X, 1000X, 10000X Max. Input Voltage 400 V (DC+AC, PK-PK, 1MΩ input impedance) (10:1 probe attenuation) Bandwidth Limit (typical) 20 MHz Horizontal Scale 5ns/div - 1000s/div, step by 1 - 2 - 52ns/div - 1000s/div, step by 1 - 2 - 55ns/div - 1000s/div, step by 1 - 2 - 52ns/div - 1000s/div, step by 1 - 2 - 5 Vertical Sensitivity 10mV/div - 10V/div Vertical Resolution 8 bits Trigger Type Edge Trigger Modes Auto, Normal, single Automatic Measurement Frequency, Period, Amplitude, Max, Min, Mean, PK-PK Cursor Measurement ΔV, ΔT, ΔT & ΔV between cursors Multimeter Max. Resolution 20,000 counts Testing Mode Voltage, Current, Resistance, Capacitance, Diode, and Continuity test Input Impedance 10 MΩ Max Input Voltage AC: 750 V | DC: 1000 V Max Input Current DC: 10 A | AC: 10 A Diode 0-2 V Other Connectivity USB Type-C Dimensions 198 x 96 x 38 mm (7.68 x 3.74 x 1.5') Weight 600 g (without batteries) Included 1x OWON HDS242 Oscilloscope 1x Soft Bag 1x Probe 1x Power Cord 1x Probe Adjust 1x USB Cable 1x Power Adapter 1x Pair of Multimeter Probe Leads (red one and black one) 1x Pair of Oscilloscope Probe Leads (BNC to Alligator Clip) 1x User Manual (English) Downloads User Manual for HDS200 Series SCPI Protocol for HDS200 Series Quick Guide for HDS200 Series PC Software for OWON HDS200 Series
The OWON HDS272S is the perfect solution all-in-one solution! Oscilloscope, multimeter and waveform generator in the same battery-powered device, to work on the go. Features Oscilloscope + multimeter + waveform generator, multifunction in one 3.5-inch high-resolution, high-contrast colour LCD display, suitable for outdoor use 18650 lithium battery, comprehensive power consumption ≤3 W, can work continuously for about 6 hours USB Type-C interface, support power bank, support PC software connection Self-calibration function SCPI supported, facilitate secondary development Specifications Oscilloscope Bandwidth 70 MHz Channels 2-ch Oscilloscope + 1-ch Generator Sample Rate 250 MSa/s Acquisition Model Normal, Peak detect Record Length 8K Display 3.5-inch LCD Waveform Refresh Rate 10,000 wfrms/s Input Coupling DC, AC, and Ground Input Impedance 1 MΩ ±2%, in parallel with 16pF±10pF Probe Attenuation Factors 1X,10X,100X,1000X,10000X Max. input Voltage 400 V (DC+AC, PK-PK, 1MΩ input impedance) (10:1 probe attenuation) Bandwidth Limit (typical) 20 MHz Horizontal Scale 5 ns/div - 1000 s/div, step by 1 - 2 - 5 Vertical Sensitivity 10 mV/div - 10 V/div Vertical Resolution 8 bits Trigger Type Edge Trigger Modes Auto, Normal, single Automatic Measurement Period, Frequency, Mean, PK-PK, Max, Min Cursor Measurement ΔV, ΔT, ΔT& ΔV between cursors Communication Interface USB Type-C Multimeter Max. Resolution 20,000 counts Testing Mode Voltage, Current, Resistance, Capacitance, Diode, and Continuity test Input Impedance 10 MΩ Max Input Voltage AC: 750 V | DC: 1000 V Max Input Current DC: 10 A | AC: 10 A Diode 0-2 V Waveform Generator Frequency Output Sine 0.1 Hz - 25 MHz Square 0.1 Hz - 5 MHz Ramp 0.1 Hz - 1 MHz Pulse 0.1 Hz - 5 MHz Arbitrary 0.1 Hz - 5 MHz Sampling Rate 125 MSa/s Channel 1-ch Amplitude Range 20 mVpp - 5 Vpp Waveform Length 8K Vertical Resolution 14 bits Output Impedance 50Ω Downloads User Manual for HDS200 Series SCPI Protocol for HDS200 Series Quick Guide for HDS200 Series PC Software for OWON HDS200 Series
Features Data-logger & Multimeter & Thermometer 3 (5/6) digits True RMS test supported BLE 4.0 wireless transmission, more stable, less power consumption Chart and Diagram mode, to analyze your data Supports NCV Voice Broadcast simplifies testing Flashlight function Built-in offline recording function Supports Android, iOS Included Test leads K-type thermocouple 9 V Battery Bolt driver Crocodile clip Quick guide
Features 4 1/2 bit resolution (20000 Counts) Data Logger Multimeter Thermometer True RMS test supported BLE 4.0 wireless transmission, more stable,less power consumption Build-in offline record function Chart and Diagram mode helps to analyze the data tendency Flashlight function lightens the darkness Support NCV non-contact voltage sense Widely supported on Android, iOS, Windows Included OWON 18E Bluetooth Multimeter Quick Guide Multimeter Lead K-type Thermocouple Bolt Driver App Download The Bluetooth function of this multimeter is compatible with Android-app version 1.5.8.0 or newer. Use the QR code in the box or go to http://files.owon.com.cn/bluetooth.
Features Channel Single Channel Output Total Output Power 180 W Channel Output 0 - 60 V / 0 - 3 A × 1-CH Display 3.7' color LCD display Dimension 117 mm(L) × 194 mm(H) × 295 mm(D) Weight Approx. 5.8 kg Interface RS232 Specifications Rated Output (0 ℃ - 40 ℃) Voltage 0 - 60 V Current 3 A Load Regulation Voltage ≤ 0.01% + 3 mV Current ≤ 0.01% + 3 mA Power Regulation Voltage ≤ 0.01% + 3 mV Current ≤ 0.01% + 3 mA Setting Resolution Voltage 1 mV Current 1 mA Readback Resolution Voltage 1 mV Current 1 mA Setpoint accuracy (within 12 months) (25 ℃ ± 5 ℃) Voltage ≤ 0.03% + 10 mV Current ≤ 0.1% + 5 mA Readback Resolution (25 ℃ ± 5 ℃) Voltage ≤ 0.03% + 10 mV Current ≤ 0.1% + 5 mA Ripple/Noise (20 Hz - 20 MHz) Voltage (Vp-p) ≤ 4 mVp-p Voltage (Vrms) ≤ 1 mVrms Current (rms) ≤ 4 mArms Output temperature coefficient (0 ℃ - 40 ℃) Voltage ≤ 0.03% + 10 mV Current ≤ 0.1% + 5 mA Readback temperature coefficient Voltage ≤ 0.03% + 10 mV Current ≤ 0.1% + 5 mA Response Time 100 μs Storage 5 groups of data Working Temperature 0 - 40 ℃
The OWON SDS1022 is a competitively priced oscilloscope with a sample rate of 1 GSa/s and a bandwidth of 20 MHz. Furthermore, with this oscilloscope you have 2 channels at your disposal and it is possible to store 10 K points per measurement. There is a USB connector on the back for exporting measurement results to the PC, and a USB port on the front for exporting to a USB memory stick.Features
Bandwidth: 20 MHz
2-Channels
Sample rate: 100 MS/s
Ultra-thin body
7' high resolution LCD
SCPI and LabVIEW supported
Specifications
Bandwidth
20 MHz
Sample Rate
100 MS/s
Horizontal Scale (s/div)
5 ns/div - 1000 s/div, step by 1 - 2 - 5
Channel
2
Display
7' color LCD, 800 x 480 pixels
Input Coupling
DC, AC and GND
Vertical Resolution (A/D)
8 bits (2 channels simultaneously)
Vertical Sensitivity
5 mV/div - 5 V/div (at input)
Trigger Type
Edge, Video
Trigger Mode
Auto, Normal, and Single
Waveform Math
＋, －, x, ÷, invert, FFT
Fuse
2 A, T class, 250 V
Dimension (W x H x D)
301 x 152 x 70 mm
Device Weight
1.10 kg
Downloads
USB Driver
PC Software
OWON SDS1102 is an affordable desktop digital oscilloscope with top features: 2-channel device with 100 MHz bandwidth, 1 GSa/s sample rate, 7' LCD display and 10 K pts wavelength. OWON SDS1102 has a simplified synchronization system which supports two trigger types: level and edge. Designed to solve problems that do not require large amounts of memory and difficult trigger types. Features Bandwidth: 100 MHz 2 channels Sample rate: 100 MS/s Ultra-thin body 7-inch high resolution LCD SCPI and LabVIEW supported Specifications Bandwidth 100 MHz Horizontal Scale (s/div) 5 ns/div – 1000 s/div Channel 2 Vertical Sensitivity 5 mV/div – 5 V/div (at input) DC Gain Accuracy 3% Vertical Resolution (A/D) 8 bits (2 channels simultaneously) Input Input Impedance 1 MΩ, 10 pF Input Coupling AC, DC, GND Max Input Voltage ±400 V, CATI, CATII Passive probes х1; х10 Probe Attenuation Factor х1; х10; х100; х1000 Trigger System Trigger Mode Auto, Normal, Single Trigger Type Edge, Video Edge Trigger Source CH1, CH2 Video Trigger Sampling Type real-time Sample Rate 1 GSa/s Equivalent Sample Rate No Wavelength 10K pts Interpolation sin(x)/x Measurement and Mathematical Treatment System Automatic Measurement Vpp, Vavg, RMS, Frequency, Period, Vmax, Vmin, Vtop, Vbase, Width, Overshoot, Pre-shootRise time, Fall time, +Width, -Width, +Duty, -Duty, Delay A→B, Delay A→B, area, cycle area Math Functions Addition, Subtraction, Multiplication, Division, FFT General Characteristics Display type 7' color LCD Display Resolution 800 x 480 Power 100-240 V, 45-440 Hz, <15 W Dimensions 301 x 70 x 152 mm Weight 1.1 kg Included 1x OWON SDS1102 Oscilloscope 2x Oscilloscope probe 1x Probe Adjust 1x Mains power cord 1x USB Cable 1x CD-Rom 1x Quickstart Guide Downloads User manual Datasheet
Bandwidth 100MHz Sample Rate 100MS/s Horizontal Scale (s/div) 5ns/div - 1000s/div, step by 1 - 2 - 5 Channel 4 Display 7' color LCD, 800 x 480 pixels Input Coupling DC, AC and GND Vertical Resolution (A/D) Vertical Resolution (A/D) Vertical Sensitivity 5mV/div - 5V/div (at input) Trigger Type Edge, Video Trigger Mode Auto, Normal and Single Waveform Math ＋, －, x, ÷, invert, FFT Fuse 2A, T class, 250 V Dimension (W x H x D) 301 mm x 152 mm x 70 mm Weight 1.1 kg Included 1 x SDS1104 1 x Mains power cord 1 x CD Rom 1 x Quickstart Guide 1 x USB Cable 4 x Oscilloscope probe 1 x Probe Adjust For more information, check out the user manual here.
The OWON SDS1202 2-channel oscilloscope features a high 200 MHz bandwidth, a sample rate of 1 GSa/s, an ultra-thin body and a 7-inch high resolution color LCD. The scope supports SCPI and LabVIEW. Features Bandwidth: 200 MHz 2 channels Sample rate: 1 GS/s Ultra-thin body 7-inch high resolution LCD SCPI and LabVIEW supported Specifications Bandwidth 200 MHz Sample Rate 1 GS/s Horizontal Scale (s/div) 2 ns/div - 1000 s/div, step by 1 - 2 - 5 Channel 2 Display 7' color LCD, 800 x 480 pixels Input Coupling DC, AC and GND Vertical Resolution (A/D) 8 bits (2 channels simultaneously) Vertical Sensitivity 5 mV/div - 5 V/div (at input) Trigger Type Edge, Video Trigger Mode Auto, Normal, and Single Waveform Math ＋, －, x, ÷, invert, FFT Fuse 2A, T class, 250V Dimension (W x H x D) 301 x 152 x 70 mm Device Weight 1.10 kg Included 1x OWON SDS1202 Oscilloscope 1x Probe 1x Probe adjust 1x Power cord 1x USB cable 1x CD-ROM 1x Quick guide Downloads Datasheet User manual PC software SCPI commands
OWON SP3103 is a compact 300 W power supply with various combinations of voltages and currents for accurate measurements for every need. Features Small body for easy carry 300 W maximum output power High resolution: 10 mV/1 mA Low ripple and noise Over-voltage/over-current protection Intelligent temperature control fan cooling 3.7-inch TFT LCD display Support RS232 digital communication Support SCPI Specifications Rated Output Voltage 0-30 V Current 10 A Output Power 300 W Load Regulation Voltage ≤30 mV Current ≤30 mA Power Regulation Voltage ≤20 mV Current ≤20 mA Setting Resolution Voltage 10 mV Current 1 mA Readback Resolution Voltage 10 mV Current 1 mA Value Resolution (within 12 months) (25℃±5℃) Voltage ≤0.1% ± 20 mV Current ≤0.05% ± 10 mA Readback Value Resolution (25℃±5℃) Voltage ≤0.1% ± 20 mV Current ≤0.1% ± 10 mA Ripple/Noise (20Hz-20MHz) Voltage (Vp-p) ≤30 mVp-p Voltage (rms) ≤3 mVrms Current (rms) ≤30 mAp-p Output temperature coefficient (0℃-40℃) Voltage ≤0.3% ± 10 mV Current ≤0.3% ± 20 mA Readback temperature coefficient Voltage ≤0.3% ± 10 mV Current ≤0.3% ± 10 mA Response Time ≤1.0 ms Storage 5 groups of data Working Temperature 0-40℃
The OWON SPE6102 is a 1-channel DC power supply (200 W) in a small body with features like over voltage and over current protection. It has a high resolution of 10 mV/1 mA. The 2.8' LCD displays the following information (constant voltage output, constant current output, cumulative running time, actual output power, channel output status, actual voltage output, actual current output).Features
Small body for easy carry
High resolution: 10 mV/1 mA
List waveform editing output, editable 10 groups of timing output function
Low ripple/noise
Over voltage / over current protection
Output voltage and current curve monitoring function
Intelligent temperature control fan cooling
2.8-inch TFT LCD display
USB communication interface, support SCPI
Specifications
Model
SPE6102
SPE6103
Rated Output (0-40°C)
Voltage
0-60 V
0-60 V
Current
10 A
10 A
Output Power
200 W
300 W
USB Output
5 V/1 A (SPE Series) or suppout QC2.0, QC3.0, BC1.2, Apple, Huawei, Samsung fast charging protocols (optional)
Load Regulation
Voltage
≤30 mV
Current
≤20 mA
Power Regulation
Voltage
≤30 mV
Current
≤20 mA
Setting Resolution
Voltage
10 mV
Current
1 mA
Readback Resolution
Voltage
10 mV
Current
1 mA
Value Resolution (within 12 months) (25 ±5°C)
Voltage
≤0.1% ±30 mV
≤0.1% ±30 mV
Current
≤0.05% ±10 mA
Readback Value Resolution (25 ±5°C)
Voltage
≤0.1% ±30 mV
≤0.1% ±30 mV
Current
Ripple/Noise
Voltage (Vp-p)
≤50mVp-p
≤50mVp-p
Voltage (rms)
≤5mVrms
≤5mVrms
Current (rms)
≤30mAp-p
Output temperature coefficient (0-40°C)
Voltage
100ppm/°C
Current
200ppm/°C
Readback temperature coefficient
Voltage
100ppm/°C
Current
200ppm/°C
Response Time (50-100% rated load)
≤1.0ms
Storage
4 groups of data
Working Temperature
0-40°C
Included
1x OWON SPE6102
1x Power Cord
1x Quick Guide
1x USB Cable
1x Fuse
Downloads
User Manual
Programming Manual
Software
The OWON SPE6103 is a 1-channel DC power supply (300 W) in a small body with features like over voltage and over current protection. It has a high resolution of 10 mV/1 mA. The 2.8' LCD displays the following information (constant voltage output, constant current output, cumulative running time, actual output power, channel output status, actual voltage output, actual current output).Features
Small body for easy carry
High resolution: 10 mV/1 mA
List waveform editing output, editable 10 groups of timing output function
Low ripple/noise
Over voltage / over current protection
Output voltage and current curve monitoring function
Intelligent temperature control fan cooling
2.8-inch TFT LCD display
USB communication interface, support SCPI
Specifications
Model
SPE6102
SPE6103
Rated Output (0-40°C)
Voltage
0-60 V
0-60 V
Current
10 A
10 A
Output Power
200 W
300 W
USB Output
5 V/1 A (SPE Series) or suppout QC2.0, QC3.0, BC1.2, Apple, Huawei, Samsung fast charging protocols (optional)
Load Regulation
Voltage
≤30 mV
Current
≤20 mA
Power Regulation
Voltage
≤30 mV
Current
≤20 mA
Setting Resolution
Voltage
10 mV
Current
1 mA
Readback Resolution
Voltage
10 mV
Current
1 mA
Value Resolution (within 12 months) (25 ±5°C)
Voltage
≤0.1% ±30 mV
≤0.1% ±30 mV
Current
≤0.05% ±10 mA
Readback Value Resolution (25 ±5°C)
Voltage
≤0.1% ±30 mV
≤0.1% ±30 mV
Current
Ripple/Noise
Voltage (Vp-p)
≤50mVp-p
≤50mVp-p
Voltage (rms)
≤5mVrms
≤5mVrms
Current (rms)
≤30mAp-p
Output temperature coefficient (0-40°C)
Voltage
100ppm/°C
Current
200ppm/°C
Readback temperature coefficient
Voltage
100ppm/°C
Current
200ppm/°C
Response Time (50-100% rated load)
≤1.0ms
Storage
4 groups of data
Working Temperature
0-40°C
Included
1x OWON SPE6102
1x Power Cord
1x Quick Guide
1x USB Cable
1x Fuse
Downloads
User Manual
Programming Manual
Software
OWON VDS1022I 2-channel USB oscilloscope (25 MHz) is a oscilloscope for use with a computer. It is powered by USB and has a small size, making it easy to take it with you. The oscilloscope is very economical. It has a shielded USB connection, reducing interference and protecting the computer against over-voltage. The multi port on the scope can be used for external triggering, trigger out or Pass / Fail output. Features 25 MHz bandwidth, and max 1 GS/s real-time sample rate 10M record length Friendly UI: FFT, or X-Y, and waveform 2 views displayed on the same screen Multi-trigger option: edge, video, slope, pulse, and alternate USB isolation – less signal inference, more PC protection USB bus powering, and LAN remote control (optional) Ultra-thin body design, easy portability Specifications Bandwidth 25 MHz Channel 2+1 (multi) Sample Rate 100 MSa/s Horizontal Scale (s/div) 5 ns/div～100s/div, step by 1～2～5 Record Length 5K Max Input Voltage 400 V (PK - PK) (DC+AC, PK - PK) 40 V (PK - PK) (DC+AC, PK - PK) Vertical Resolution (A/D) 8 bits (2 channels simultaneously) Model VDS1022I Vertical Sensitivity 5 mV/div～5 V/div Trigger Type Edge, Pulse, Video, Slope, and Alternate Trigger Mode Auto, Normal, and Single Acquisition Mode Sample, Peak Detect, and Average Waveform Math ＋, －, ×, ÷, invert, FFT Communication Interface USB 2.0 (isolation) Multi-function Interface Signal Type Level Standard TTL Power Supply 5.0 V/1 A Power Consumption ≤2.5 W Dimensions (W × H × D) 170 x 120 x 18 mm Weight 0.26 kg Included 1x OWON VDS1022I oscilloscope 1x CD-ROM 1x Quick start guide 2x Oscilloscope probe 1x Probe tool 1x Power adapter 1x USB cable 1x Silicone case protectors 1x Power cable Downloads Datasheet User manual SCPI protocol USB driver
The 2-channel OWON XDG2035 is a function/waveform generator that can generate signals with a maximum frequency of 35 Hz. The generator has a resolution of 1 µHz and a sample rate of 500 MSa/s.The OWON XDG2035 is capable of generating 6 standard waveforms and 150 arbitrary waveforms. With the included software you can write advanced functions up to 10 million points. Waveforms can be saved to the function generator's internal memory using a PC via USB or LAN.The OWON XDG2035 also supports SCPI commands and LabView. The function generator has an integrated high-quality frequency counter, which can operate from 100 to 200 MHz.Features
Max. 35 MHz frequency output
500 MSa/s Sample rate, Vertical resolution 1μHz
14 bits Vertical Resolution, 10 Marb waveform length
Comprehensive waveform output: 6 basic waveforms,and 150 built-in arbitrary waveforms
Comprehensive modulation functions: AM, FM, PM, FSK, 3FSK, 4FSK, PSK, OSK, ASK, BPSK, PWM, Sweep, and Burst
High-accuracy frequency counter integrated, supported range 100-200 MHz
SCPI and LabVIEW supported
7 inch multi-touch screen (800 x 480 pixels)
Specifications
Channel
2
Frequency Output
35 MHz
Sample Rate
500 MSa/s
Vertical Resolution
14 bits
Waveform
Standard Waveform
sine, square, pulse, ramp, noise, and harmonic
Arbitrary Waveform
exponential rise, exponential fall, sin(x)/x, step wave, and others, total 150 built-in waveforms, and user-defined arbitrary waveform
Frequency (resolution 1 μHz)
Sine
1 μHz-100 MHz
Square
1 μHz ~ 30 MHz
Pulse
1 μHz ~ 25 MHz
Ramp
1 μHz ~ 3 MHz
Noise (-3 dB, typical)
100 MHz
Arbitrary Waveform
1 μHz ~ 15 MHz
Harmonic
1 μHz ~ 50 MHz
Accuracy
±2ppm, 25°C ±5°C
Waveform Length
2 points - 10M points
Amplitude
Into 50Ω load
1mVpp ~ 10Vpp (≤25 MHz); 1mVpp ~ 5Vpp (≤60 MHz); 1mVpp ~ 2.5Vpp (≤100 MHz)
Modulation
Type
AM, DSB-AM, FM, PM, ASK, FSK, PSK, BPSK, QPSK, 3FSK, 4FSK, OSK, PWM, SUM
Frequency Counter
Function
Frequency, period, +width, -width, +duty, and -duty
Frequency Range
100 ~ 200 MHz
Frequency Resolution
7 digits
Input/Output
Input mode
frequency counter, external modulation input, external trigger input, internal clock output, external reference clock input/output
Communication Interface
USB Host, USB Device, LAN, RS232 (optional)
Mechanical specifications
Dimensions
340 x 177 x 90 mm
Weight
2.3 kg
Included
1x OWON XDG2035
1x Power Cord
1x CD-ROM
1x Quick start guide
1x USB Cable
1x BNC-BNC Cable
DownloadsQuick Guide
