JOY-iT Expansion Board with CAN and RS485 Interface for Raspberry Pi Pico

  • BrandJOY-iT

Description

This expansion board allows you to add an RS485 and a CAN interface to a Raspberry Pi Pico.

The board also offers the option of operating it either via a standard USB-C connection with 5 V or via a screw terminal that accepts a voltage of 6 to 12 V. The voltage applied to the screw terminal is reduced to 5 V by a voltage converter integrated on the board.

Features

  • Power can be supplied via a USB-C connection with 5 V or via a screw terminal that draws between 6 and 12 V. In the latter case, a built-in voltage converter reduces the voltage to 5 V.
  • To increase the versatility and range of functions, the connection pins of the Raspberry Pi Pico have been routed to the outside.
  • The expansion board also offers the option of communication via the RS485 and CAN interfaces.

Specifications

CAN Interface SPI, CAN
RS485 Interface Serial, RS485
Power supply 5 V DC (USB-C)
Screw terminal 6-12 V DC
Logic level 3.3 V
Terminating resistor CAN 120 Ω (can be activated and deactivated as required)
Terminating resistor RS485 120 Ω (can be activated and deactivated as required)
Product form

This expansion board allows you to add an RS485 and a CAN interface to a Raspberry Pi Pico. The board also offers... Read more

€ 14,95 incl. VAT
Members € 13,46

      Shipping may take longer during the festive season.

    Details

    SKU: 21006
    EAN: 4250236826813

    Description

    This expansion board allows you to add an RS485 and a CAN interface to a Raspberry Pi Pico.

    The board also offers the option of operating it either via a standard USB-C connection with 5 V or via a screw terminal that accepts a voltage of 6 to 12 V. The voltage applied to the screw terminal is reduced to 5 V by a voltage converter integrated on the board.

    Features

    • Power can be supplied via a USB-C connection with 5 V or via a screw terminal that draws between 6 and 12 V. In the latter case, a built-in voltage converter reduces the voltage to 5 V.
    • To increase the versatility and range of functions, the connection pins of the Raspberry Pi Pico have been routed to the outside.
    • The expansion board also offers the option of communication via the RS485 and CAN interfaces.

    Specifications

    CAN Interface SPI, CAN
    RS485 Interface Serial, RS485
    Power supply 5 V DC (USB-C)
    Screw terminal 6-12 V DC
    Logic level 3.3 V
    Terminating resistor CAN 120 Ω (can be activated and deactivated as required)
    Terminating resistor RS485 120 Ω (can be activated and deactivated as required)
